Descripción

Nominal voltage: 48V
Nominal capacity: 4800Wh
Discharge depth: 96%
Useful capacity: 4560Wh
Dimensions in mm: 515*493*175
Weight: 41kg
Discharge voltage: 44.5 ~ 53.5V
Charging voltage: 52.5~53.5
Recommended charge and discharge current: 50A
Maximum charge and discharge current: 100A (It can offer 120A for 15 minutes and up to 200A for 15 seconds)
Communication ports: RS485 and CAN
Maximum parallelization capacity: Up to 16 units can be put in parallel
Working temperature range: -10º~65º
Admissible humidity range: 5%~95% (Despite this, it is not recommended to have it in humid and/or poorly ventilated places)
Maximum working altitude: <2000m
Estimated useful life: +15 years (with working temperature at 25º)
Estimated life cycles: Up to 6,000 cycles (with working temperature at 25º)
