Descripción

Nominal Voltage (V): 48
Nominal Capacity (Wh): 2400
Usable Capacity (Wh): 2200
Dimensions (WDH, mm): 442 × 410 × 89
Weight (kg): 24
Discharge Voltage (V): 45 ~ 53.5
Charge Voltage (V): 52.2 ~ 53.5

Charge/Discharge Current (A):
25 (recommended)
50 (max)
100 (peak @ 15s)

Communication Port: RS485, CAN
Single String Quantity (pcs): 8
Working Temperature (°C): -20 ~ 60
Shelf Temperature (°C): -20 ~ 60
Humidity: 5% ~ 85%
Altitude (m): < 4000
Design Life: 15+ Years (25°C @ 77°F)
Cycle Life: > 6000 @ 25°C
Authentication Level: UL/IEC62619/CE/UN38.3
